    OCEAN CRAFT MARINE FIBERGLASS BOATS

    Our unique surface-effect, reverse-chine Air hull® guarantees your boat will outperform any other boat with outstanding performance, stability and remarkable high-speed tactical turns. The Ocean Craft Marine Fiberglass boat will excel in the roughest of sea conditions.

    Our exclusive Air Hull ® formed by Reverse U Chines Hull design greatly adds to the boat’s sea-keeping, guaranteeing your boat will out-perform any other boat with precise turning capabilities, inherent lift and the ability to navigate in more extreme sea conditions.

    ENQUIRE NOW

      OCEAN CRAFT MARINE FIBERGLASS BOATS

      Our unique surface-effect, reverse-chine Air hull® guarantees your boat will outperform any other boat with outstanding performance, stability and remarkable high-speed tactical turns. The Ocean Craft Marine Fiberglass boat will excel in the roughest of sea conditions.

      Our exclusive Air Hull ® formed by Reverse U Chines Hull design greatly adds to the boat’s sea-keeping, guaranteeing your boat will out-perform any other boat with precise turning capabilities, inherent lift and the ability to navigate in more extreme sea conditions.

      Ocean Craft Marine’s exclusive Air Hull® design enhances

      your on-water experience in several ways:
      1

      Smoother and quieter ride: The Air Hull® makes the boat more stable and helps keep the balance at the keel even at top speeds.

      2

      Dry Ride: The reverse chines deflect the water that splashes up from the propulsion and helps keep the deck dry.

      3

      Enhanced performance: The reverse Chines ensure a smooth and seamless propulsion as well as a quick and effortless acceleration, which helps the boat almost glide on the water.

      4

      Increased efficiency and ability to handle sharp turns.

      BASIC CONFIGURATION

      OPTIONS

      OCM designs and manufactures customized Rigid Inflatable Boats (RIBs) to meet each customer’s specific needs. Explore our interactive render to see all the available options for customizing every inch of the boat, from the cabin to the deck. Simply click on a section to see the options and choose the ones that best suit your needs. Our goal is always to exceed customer expectations and meet unmet needs

      SPECIFICATIONS
      6.5 M
      7.2 M
      8.0 M
      8.5 M
      9.5 M
      12 M

      6.5 M

      Length Overall
      6.7 m – 22′

      Beam Overall
      2.52 m – 8’3″

      Lightship Weight
      1,369 kg – 3,018 Ibs

      Payload
      1,185 kg – 2,612 Ibs

      Collar
      Air or Foam

      Tube Diameter
      0.45 m – 1’6″

      No of Air Chambers
      5

      Rec. Power
      150 Hp

      Max. Power Allowed
      250 Hp

      Max. Speed
      93 km/h – 58 mph

      Max. Fuel Capacity
      100 US Gal – 380 Ltr

      No of Pax
      9

      Propulsion
      Outboard / Inboard

      Classification
      B

      7.2 M

      Length Overall
      7.5 m – 24’7″‘

      Beam Overall
      2.5 m – 8’2″

      Lightship Weight
      1,360 kg – 2,998 Ibs

      Payload
      1,169 kg – 2,577 Ibs

      Collar
      Air or Foam

      Tube Diameter
      0.45 m – 1’6″

      No of Air Chambers
      5

      Rec. Power
      200 Hp

      Max. Power Allowed
      300 Hp

      Max. Speed
      89 km/h – 55 mph

      Max. Fuel Capacity
      60 US Gal – 255 Ltr

      No of Pax
      10

      Propulsion
      Outboard / Inboard

      Classification
      C

      8.0 M

      Length Overall
      8.2 m – 26’11”

      Beam Overall
      2.55 m – 8’4″

      Lightship Weight
      1,856 kg – 4,091 Ibs

      Payload
      1,441 kg – 3,177 Ibs

      Collar
      Air or Foam

      Tube Diameter
      0.45 m – 1’6″

      No of Air Chambers
      5

      Rec. Power
      2×150 Hp

      Max. Power Allowed
      2×250 Hp

      Max. Speed
      109 km/h – 68 mph

      Max. Fuel Capacity
      120 US Gal – 455 Ltr

      No of Pax
      15

      Propulsion
      Outboard / Inboard

      Classification
      B

      8.5 M

      Length Overall
      8.8 m – 28’10”

      Beam Overall
      3.17 m – 10’5″

      Lightship Weight
      2,312 kg – 5,097 Ibs

      Payload
      1,750 kg – 3,858 Ibs

      Collar
      Air or Foam

      Tube Diameter
      0.56 m – 1’10”

      No of Air Chambers
      5

      Rec. Power
      2×200 Hp

      Max. Power Allowed
      2×300 Hp

      Max. Speed
      118 km/h – 73 mph

      Max. Fuel Capacity
      158 US Gal – 600 Ltr

      No of Pax
      13

      Propulsion
      Outboard / Inboard

      Classification
      C

      9.5 M

      Length Overall
      9.7 m – 31’10”

      Beam Overall
      3.17 m – 10’5″

      Lightship Weight
      2,580 kg – 5,688 Ibs

      Payload
      1,950 kg – 4,299 Ibs

      Collar
      Air or Foam

      Tube Diameter
      0.56 m – 1’10”

      No of Air Chambers
      7

      Rec. Power
      2×250 Hp

      Max. Power Allowed
      2×400 Hp

      Max. Speed
      121 km/h – 75 mph

      Max. Fuel Capacity
      197 US Gal – 746 Ltr

      No of Pax
      15

      Propulsion
      Outboard / Inboard

      Classification
      B

      12 M

      Length Overall
      12.2 m – 40′

      Beam Overall
      3.75 m – 12’4″

      Lightship Weight
      5,544 kg – 12,222 Ibs

      Payload
      2,742 kg – 6,045 Ibs

      Collar
      Air or Foam

      Tube Diameter
      0.56 m – 1’10”

      No of Air Chambers
      9

      Rec. Power
      2×350 Hp

      Max. Power Allowed
      2×350 Hp

      Max. Speed
      129 km/h – 80 mph

      Max. Fuel Capacity
      298 US Gal – 1130 Ltr

      No of Pax
      15

      Propulsion
      Outboard / Inboard

      Classification
      B
